Check
Point
Factsheet:
IP
Appliance—Model
IP1287
1
7
8
9
2
3
4
5
6
1.
Optional
redundant
hard
disk
drives
w/carriers
2.
Console
port
3.
Auxiliary
port
4.
USB
port
5.
PMC
expansion
slot
for
optional
PMC
or
XMC
network
interface
cards
6.
Management
and
sync
ports
7.
Optional
PMC/XMC
network
interface
cards
(6U
carrier
is
needed)
or
ADP
module
(comes
with
carrier)
8.
Optional
PMC/XMC
network
interface
cards
(6U
carrier
is
needed)
or
ADP
module
(comes
with
carrier)
9.
Slide-out
chassis
tray
Performance
without
ADP/with
ADP
TECHNICALSPECIFICATIONS
LAN
Support
•
10/100
Base-T
(10/100
Mbps
Ethernet)
—
PCI
Mezzanine
Card
(PMC)
•
1000Base-T
(10/100/1000
Mbps
Ethernet)
—
PMC
•
1000Base-SX
(1000
Mbps
Ethernet)
—
SFP,
Multi-Mode
Fiber
(MMF)
ADP
•
1000Base-LX
(1000
Mbps
Ethernet)
—
SFP,
Single-Mode
Fiber
(SMF)
ADP
•
10
GBase-SR
(10
Gbps
Ethernet)
—
XFP,
MMF
ADP
•
10
GBase-LR
10
km
(10
Gbps
Ethernet)
—
XFP,
SMF
ADP
•
One
ADP
module
can
be
installed
in
the
system
Performance
•
Firewall
—
10.3/17.5
Gbps
1
•
VPN
—
1.9/8.3
Gbps
•
Maximum
concurrent
sessions
–
1
million
•
IPS
—
7
Gbps
System
Indicators
•
10/100/1000
Ethernet
port
status
•
Power
status
on
system
•
Failure
status
on
system
•
Port
status
on
network
interface
cards
•
System
operational
indicator
1
Note:
Performance
data
represents
the
maximum
capabilities
of
the
systems
as
measured
under
optimal
testing
conditions.
Dimensions
•
Standard:
17.23
x
24.11x
3.46
in.
•
Metric:
438
x
613
x
88mm
•
Weight:
19.6kg
(43.2
lbs)
Power
Requirements
•
AC
Input
voltage:
100-240V
•
Frequency:
50/60Hz
•
AC
input
current
maximum:
8.3-3.4A
•
DC
input
voltage:
40-60V
•
DC
input
current
maximum:
20-13A
•
Maximum
power
dissipation:
700W
(2,388
BTU/hr)
Environment
Operating
Conditions
•
Temperature:
41°-104°F
/
5°-40°C
•
Altitude:
8,202
ft
/
2500
m
•
Humidity:
10%-85%
(non-condensing)
Environment
Non-Operating
Conditions
•
Temperature:
0°C
to
+70°C
•
Humidity:
Up
to
at
least
95%
(non-condensing)
Compliance
UL60950-1,
First
Edition:
2003,
CAN/CSAC22.2,
No
60950:2000,
IEC60950-1:
2001,
EN60950-1:2001+A11
with
Japanese
National
Deviations,
FCC
Part
15,
Subpart
B,
Class
A,
EN50024,
EN55022A:
1998,
CISPR
22
Class
A:
1985,
EN61000-3-2,
EN61000-3-3,
EN55024:
1998
and
RoHS.
©2011
Check
Point
Software
Technologies
Ltd.
All
rights
reserved.
Classification:
[Unrestricted]
—
