Check
Point
Factsheet:
Power-1
Appliance Model
9077
5
2
3
4
10
1
6
7
8
9
1.
Redundant
Hot-Swappable
Hard
Drives
2.
LCD
Display
3.
LCD
Control
Buttons
6.
Console
Port
7.
USB
Ports
8.
8
x
1GbE
Ports
4.
Air
Intake
5.
Management
&
Sync
Ports
9.
10.
Field
Swappable
Expansion
Modules
(Basic
configuration
includes
4
1GbE
Ports
Module)
•
1
Gbe
Copper
(4
Ports)
•
1
GbE
SX
Fiber
(Multi
Mode)
(4
Ports)
•
1
GbE
LX
Fiber
(Single
Multi
Mode)
(4
Ports)
•
10
GbE
SR
Fiber
(Multi
Mode)
(2
Ports)
•
10
GbE
LR
Fiber
(Single
Mode)
(2
Ports)
Lights-Out
Management
Module
(Optional
Out-Of-Band
Management)
TECHNICAL
SPECIFICATIONS
LAN
Support
•
1000Base-T
(10/100/1000
Mbps
Ethernet)
-
Copper
•
1000Base-SX
(1000
Mbps
Ethernet)
-
SFP
•
1000Base-LX
(1000
Mbps
Ethernet)
-
SFP
•
10
GBase-SR
300
meters
(10
Gbps
Ethernet)
-
Multi
Mode
•
10
GBase-LR
10
km
(10
Gbps
Ethernet)
-
Single
Mode
Hard
Disk
Configuration
•
2
X
160
GB
HDD
Performance
•
Firewall
-
16
Gbps
•
VPN
-
3.7
Gbps
•
IPS
-
10
Gbps
•
Concurrent
Sessions
-
1.2
Million
Note:
Performance
data
represents
the
maximum
capabilities
of
the
systems
as
measured
under
optimal
testing
conditions.
Dimensions
•
Standard:
17x
20x
3.46
in.
•
Metric:
431
x
509.5
x
88mm
•
Weight:
16.5kg
(36.3
lbs)
Power
Requirements
•
AC
Input
Voltage:
100-240V
•
Frequency:
50/60Hz
•
Power
supply
Maximum:
400W
•
Power
Consumption
Maximum:
200.7W
Environment
Operating
Conditions
•
Temperature:
41°-104°F/5°-40°C
•
Altitude:
8196ft,
2,500
m
•
Humidity:
10%-85%
(Non-Condensing)
Compliance
UL
60950;
FCC
Part
15,
Subpart
B,
Class
A;
EN
55024;
EN
55022;
VCCI
V-3AS/NZS
3548:1995;
CNS
13438
Class
A
(test
passed;
country
approval
pending);
KN22KN61000-4
Series,
TTA;
IC-950;
ROHS
